CYLINDERS - PISTONS (KOENIG)

CYLINDERS - PISTONS (ASSO WERKE) FOR DUCATI XDIAVEL DARK 2021

HALF CRANKCASES

Item numbers
CYLINDERS - PISTONS (ASSO WERKE) Ducati Motorcycle Diavel 2021 XDiavel Dark XDiavel Dark
1
1
1
1
1
2
2
2
2
3
3
4
4
5
5
5
6
7
7
8
8
9
10
11
11
12
12
13
1
PISTON ASSY

12222352A  

12222491A

Unit Price Incl. Tax

2
CIRCLIP, PISTON PIN

12112481A  

Unit Price Incl. Tax

3
PISTON PIN

12110781B  

12110781C

Unit Price Incl. Tax

4
PISTON RING SET

12120791A  

Unit Price Incl. Tax

5
CYLINDER-PISTON FIT HORIZONTAL

12022804D  

Unit Price Incl. Tax

6
GASKETS SET

79120561D  

Unit Price Incl. Tax

7
CYLINDER-PISTON FIT VERTICAL

12022812D  

12022814D

Unit Price Incl. Tax

8
GASKET, CYLINDER

78611251A  

Unit Price Incl. Tax

9
STUD BOLT

76611102A  

Unit Price Incl. Tax

10
WASHER

85212771A  

Unit Price Incl. Tax

11
HEAD-CYLINDER GASKET

78611401D  

Unit Price Incl. Tax

12
PIN DOWEL

71112191A  

Unit Price Incl. Tax

13
NUT

74840482A  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Ducati. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Ducati, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
